High Pressure Crate Washer
A water jetting machine innovated by Goma Engineering for deep cleaning the crate through a rapid force of water, removing every dirt from the surface in no time.
Goma’s High-Pressure Crate washer has been successfully working in various industries. The crates/trays are washed thoroughly by high-pressure water jetting. There is no requirement for steam, detergent, chemicals, etc. Thus, there is a saving in cost & energy as compared to a conventional crate washer.
General Arrangement & Operation
The crates/ trays are conveyed automatically by a conveyor chain fitted on a stainless steel fabricated frame. The crates/trays pass through specially designed High-Pressure Water Jet Nozzles having accurate spray angles for washing. The high pressure is generated by a high-pressure pump driven through an electric motor & mounted close to the conveyor.
Advantages
High Pressure jetting system for efficient cleaning
Fully automatic & continuous duty
Very compact and Easy to install
Ensures optimum cleaning in the fastest possible time
Compact design for space-saving
Time and manpower saving
No need for steam, chemicals, detergents, etc
Easy for operation and maintenance
A special cleaning system can be designed for higher-pressure
Technical Specifications:
|
Working Pressure |
60 - 120 Kg / cm² (as per cleaning required) |
|
Water Consumption |
60 - 100 L.P.M. (Water can be reused by adopting a special filtration system) |
|
Power Consumption |
15 - 70 HP (as per pressure requirement) |
|
Speed of Crate Washing |
300 to 2000 crates/hr |
|
Overall size |
3000 mm (L) X 900 mm (W) X 1500 mm (H) |
